Radiators

Construction & sanitation

Optimum product properties, high quality and profitability – the FreiLacke coating systems for radiators

For many years, FreiLacke coating systems have been the medium of choice for coating radiators and heaters. This is due to their extraordinary durability and outstanding processing properties on steel, aluminium, cast iron and lots more. However, it is also due to the efficient processes that FreiLacke has developed especially for this industry sector. For example, the two-layer coating of radiators with an anodic EC “rewash” primer and a powder top coat. A FreiLacke process that combines high quality standards with optimum profitability. FreiLacke is the only medium-sized company to offer powder coating, water deposition coating and electrodeposition coating technologies from a single source.

Application example Radiators

Lacksysteme für Radiatoren

E-coatings

High quality e-coats for coating conductive substrates.

More information

1 of 3

Powder coatings

One of the most modern types of coatings for all different requirements.

More information

2 of 3

Liquid coatings

fit-for-purpose and competitively priced “allround coatings”

More information

3 of 3

Advantages for radiators

Radiators can be coated perfectly using a two-layer process

A good example of a coating solution that meets these requirements is the two-layer coating of radiators with an anodic EC “rewash” primer and a powder top coat. This is a FreiLacke process that combines high quality standards with optimum profitability. In anodic dispersion coating (ADC), the coating material is first immersed in an electrically conductive, aqueous electro-deposition coating, then a DC voltage field is applied between the coating material (as the anode) and a counter-electrode (as the cathode). A water-soluble binding agent is then deposited on the surface of the radiators connected as electrodes (electro-coagulation) to create a sealed, adhesive coating film. The powder top coat then enables to give the surface some highly flexible design options with various coarse or fine structures and gloss categories.

A one-stop shop for the most innovative coating technologies

FreiLacke is the only medium-sized company in Germany to offer radiator manufacturers powder coating, water deposition coating and electro-deposition coating technologies from a single source. For you as a customer, this gives you the opportunity to obtain high-quality coating solutions without having to compromise on cost-effectiveness. You too can benefit from these advantages – including the consulting expertise of our experienced employees!

Application examples Radiators

Brochure Radiators

Further brochures for construction & sanitation

Contact us – we are there for you!

Do you need an individual solution for your coating? If so, get in touch with our experts. We will be happy to advise you about the perfect solution for your requirements. Your direct point of contact.
